UPS EVO DSP PLUS TT 40KVA – PF 1 | 3-Phase | VFI Online | Without Batteries - Made in Italy

The UPS EVO DSP PLUS TT 40.0 is a high-performance online UPS system built to support critical infrastructures across data centers, industrial automation, electromedical, and IT networks. It offers a true online double conversion (VFI-SS-111) design, ensuring zero transfer time and maximum protection against:

• Blackouts

• Voltage fluctuations

• Frequency shifts

• Harmonics and surges

• Lightning and voltage distortion

Performance Highlights:

• 40KVA / 40KW Capacity

• Three-phase Input/Output: 400Vac

• Unity Power Factor (PF 1)

• Efficiency: 96% in full load

• Supports 64x 12V (7.2–11Ah) batteries (not included)

• Compatible with internal or external battery banks

Key Features:

• Transformerless On-Line Double Conversion

• Zero ms transfer time

• Static and manual bypass

• Frequency converter mode

• Dual input: Rectifier and bypass

• Active PFC with 0.99 input power factor

• Crest factor 3:1

User & Communication Interface:

• Large LCD Touchscreen Display

• USB, RS232, and EPO ports

• Intelligent slot for SNMP, Dry Contact, or MODBUS card (optional)

• Fully supported by TecnoManager software (downloadable)

Technical Snapshot:

• Model Code: FGCEDP40TT2/00

• Dimensions (W x H x D): 30x100x81.5 cm

• Weight: 95 Kg

• IP Rating: IP20

• Cooling: Fan cooled

• Certifications: CE (IEC EN 62040-1/2/3)

Environmental Tolerance:

• Operating Temperature: 0°C to 55°C (optimal: 20–25°C)

• Max Altitude: 3000m

• Humidity: <95% (non-condensing)

Bulk Orders:
For bulk purchases, contact us at info@gepcomtech.com

Approximate Delivery Time : 3 Days

Datasheet
